FUNDICIONES JOAQUIN BERECIARTU, S.A.

img_014
fabrica-91
img_004
img_002_1 copy
logo (2)
img_007
logo (1)
fabrica-213
fabrica-109
certificados

  • ADDRESS C/ Urola s/n
    20230, Legazpia
  • TELEPHONE / FAX
    T +34 943730098
    F +34 943733596
  • CONTACT PERSON
    Mr. Ernesto Ruiz
  • SOCIAL NETWORKS
  • 1967
    Established
  • 4.000 m2
    Total area
  • 3.0000 m2
    Covered area

Exports

7%: Switzerland, France..

Employees 25

Management: 3

Foundry: *|plantilla_fundicion|*

Ways: *|plantilla_vias|*

Technical Dept.: 2

Commercial: *|plantilla_comerciales|*

Mecanization: *|plantilla_mecanizacion|*

Admin. staff: 1

Production: 19

Sales: *|plantilla_ventas|*

Maintenance: *|plantilla_mantenimiento|*

Production per material (t/year)

STEEL

  • Low and medium alloyed steel: 1000

Customer sectors

  • Construction
  • Lifts, forklifts, cranes, handling equipment
  • Hydroelectric power
  • Railway industry
  • Hydraulic
  • Paper and pulp industry
  • Machine tools
  • Agricultural machinery
  • Mining, cement, crushing
  • Shipbuilding and components
  • Valves, pumps, turbines and compressors

Typical parts

  • Railway industry: components and structures for trains and infrastructure
  • Medium-alloy steel castings that require superior machinability and excellent weldability. Complex and variable geometries
  • Machinery (public Works / capital godos): high resistant parts, high mechanical requirements. Parts with high resistance for fatigue, wear and hardness
  • Shipbuilding: components with high requirements with regards to wear (wheel treads and similar), and resistance to corrosion.
  • Industrial: components for lifting, couplings, handling
  • Construction: components for safety structures (bridges, offshore platforms and major works)
  • Safety-related components that respond to high mechanical demands

Production facilities

MELTING

  • Inductotherm Inducion Furnace. Melting process using a 2 Tn Induction Furnace. The alloy is controlled and inspected using a spectrometer and software.

MOULDING

  • Green sand moulding:
  • Semi-automatic green sand moulding. Carousel of moulds.
  • Dimensions of box: 850 x 550 mm.
  • Semi-automatic furan chemical moulding:
  • Automatic sand mixer,
  • Dimensions of mould: up to 2,000 x 1,000 mm.
  • Manual chemical moulding:
  • Automatic sand mixer,
  • Manual moulding in a metal box of up to 1,500 x 1,500 mm

OTHER SERVICES

  • Own: Casting design: study and simulation of the smelting, patterns and geometry, Inspection and Quality Control Testing, I+D
  • Subcontracted: Heat Treatment, Machining, Surface Treatments

Quality control and testing equipment

  • - NDT (non-destructive testing): magnetic particles, ultrasound, radiography, penetrant liquids, hardness tests.
  • - DT (destructive testing): tensile and compression tests, resilience (charpy) tests.

Weight range

  • From 1 to 1000 kgs.
  • Most competitive weight range: from 10 ta 200 kgs

Moulding system

  • Chemical flasklees
  • Sand (hand moulding)
  • Sand machine (horizontal)

Homologations/certifications

  • Det Norske Veritas
  • Germanischer Lloyd
  • ISO 9001
  • Lloyd's Register

Batch range (u/month)

  • From 20 until 300
  • Most competitive series: from 100 to 300 parts
